1. Upgraded tensioning structure—more robust and reliable. The walking tensioning system uses an oversized tension spring + self-lubricating bearing structure, improving operational stability and preventing spring failure.
2. Unique belt transmission structure—smoother transmission. The unique non-winding structure ensures each belt drives only one load, reducing belt stress, extending service life, ensuring more stable power transmission, and lowering maintenance costs.
3. Efficient cleaning structure—improved cleaning performance. Unique curved stainless steel fan blades provide greater air volume and a wider adjustment range.
4. Upgraded reel structure—reduced tangling and smoother operation. All elastic teeth are used, and protective covers can be installed, effectively enhancing anti-tangling capability and improving the harvesting effect for lodged crops.
5. One rod control hydraulic steering, convenient operation, can be adapted to multiple working condition, reduce labor working. A/C with warm and cold wind Cabin is optional.

Overall dimension (L x W x H) (mm) : 5170 x 2620 x 2930

Cutting Width (mm)  : 2200

Complete machine weight (kg) : 3750

Feeding capacity (kg/s): 6

Min. Ground clearance (mm) : 330

Rubber track : Φ640 × 2041

Threshing cylinder (mm) : Dry, horseshoe

Grain tank capacity (L) : 1400

Oil tank capacity (L) : 210

Working efficiency (hm2/h) : 0.35-0.6

Oil consumption (kg/hm2) : ≥32

HST: 1830

Model : Xinchai stage II

Tipe : Four cylinders, intercooling turbo, 4 stroke

Standard power (kw) : 75

Standard speed (r/min) : 2400

Model : LQ85

Gears : Three gears
